BMW 2A82 and 2A87 Codes: VANOS Faults Explained and How to Fix Them

A BMW 2A82 code is one of the most common BMW-specific fault codes found by owners who scan their car with a BMW-capable diagnostic tool. It usually appears with a check engine light and a sudden loss of power, and it is often accompanied by its twin, the 2A87 code. Both point to the VANOS variable camshaft timing system, which is a key part of BMW’s six-cylinder engines.

The good news is that BMW has documented these faults in detail. In this guide we explain what the BMW 2A82 and 2A87 codes mean, which engines and models are most affected, what BMW’s own service bulletins recommend, which recalls and warranty extensions apply, and what owners should check before paying for an expensive repair.

What Does the BMW 2A82 Code Mean?

BMW uses its own manufacturer-specific fault codes alongside generic OBD-II codes. According to BMW Service Information Bulletin SI B11 02 08, filed with NHTSA, the fault code texts are:

In simple terms, the engine computer, called the DME, asked the intake or exhaust VANOS unit to move the camshaft to a new position, and the camshaft did not get there quickly enough or at all. The 2A82 code refers to the intake side, while the 2A87 code refers to the exhaust side. Codes 130108 and 130308 are the equivalent faults on later F-series cars.

What Is VANOS?

VANOS is BMW’s variable camshaft timing system. It uses engine oil pressure, controlled by electric solenoids, to rotate the intake and exhaust camshafts relative to the crankshaft. This helps the engine deliver more torque, better efficiency and lower emissions across the rev range. Because VANOS depends on oil pressure, oil quality and the condition of the solenoids are critical to how well it works.

BMW 2A82 Code Symptoms

BMW’s bulletin describes a typical pattern. The faults usually appear after extended driving with the engine at full operating temperature, and they come with a clear set of symptoms:

• The check engine or Service Engine Soon light comes on
• Engine power is reduced, sometimes noticeably
• A check control message appears in the instrument cluster
• Rough running or hesitation, especially when the system tries to adjust the camshafts quickly
• On some cars, a rattle from the engine compartment, which BMW links to a separate VANOS bolt problem described below

On cars with the N54 twin-turbo engine, BMW notes that boost-related codes such as 120408 and 3100 can also be stored as a secondary effect of the VANOS fault. Those codes do not necessarily mean the turbo system has failed.

Common Causes of the BMW 2A82 and 2A87 Codes

Insufficient Oil Supply to the VANOS Units

BMW’s SI B11 02 08 states that the faults are linked to insufficient oil pressure reaching the intake VANOS adjustment unit. When the system must move a camshaft quickly and the camshaft lags behind or misses its target, the DME stores the fault and reduces power. Low oil level, old oil or a clogged oil supply can all contribute.

Faulty VANOS Solenoids

The same bulletin explains that restricted or failed VANOS solenoids, or problems with their wiring, can starve the VANOS assemblies of oil. The solenoids act as electrically controlled valves, and if one sticks or is blocked by debris, the camshaft cannot move as commanded. This is one of the most common real-world causes of a BMW 2A82 code.

Missing Oil Filter Cap Insert

BMW specifically instructs technicians to check whether the oil filter cap insert is installed. If it is missing, the entire oil filter housing cap must be replaced. BMW notes that this repair is not covered under warranty as a material or workmanship defect.

Loose or Broken VANOS Bolts

A separate and more serious cause affected many 2010 to 2012 models. According to BMW bulletin SI B12 14 12, filed with NHTSA, the bolts that hold the VANOS gear assemblies together could loosen or break on N51, N52K, N52T and N55 engines. The bulletin lists 2A82 and 2A87 among the fault codes this can trigger, along with symptoms such as engine rattling and power loss.

BMW 2A82 Code: Recalls and Warranty Extensions

VANOS Bolt Recalls

In April 2014, BMW recalled 156,137 vehicles in the US with six-cylinder engines because the bolts securing the VANOS unit housings could loosen or break, as reported by Motor Authority. The recall covered 2010 to 2012 3 Series, 5 Series, 5 Series Gran Turismo, X3, X5, X6, Z4 and 1 Series models.

BMW followed up with recall 23V707 in 2023, covering 155,627 US vehicles, again to replace the VANOS housing bolts. According to Motor Authority, it included 2010 to 2012 1 Series and 3 Series models and 2010 to 2011 5 Series, X3, X5 and Z4 models. Owners can check any VIN for open recalls on the NHTSA recalls website.

10-Year VANOS Warranty Extension

BMW also issued bulletin SI B01 10 14, which extended the limited warranty on the intake and exhaust VANOS adjustment units to 10 years without a mileage limit for certain non-turbocharged six-cylinder engines (N51, N52K and N52T), built roughly between 2009 and 2012. Because the coverage runs from the original in-service date, most of these cars have now passed the 10-year limit.

Affected BMW Engines and Models

BMW’s bulletins cover a wide range of six-cylinder models from the E-series and early F-series era. The table below summarizes the main groups.

How to Fix a BMW 2A82 Code

BMW’s official repair process in SI B11 02 08 follows a clear order, and independent shops generally use the same logic:

• Run the test plans: complete BMW’s diagnostic test plans for all stored faults first.
• Check for open recalls: if the VANOS bolt recall applies and is open, that repair comes first.
• Replace the VANOS solenoids: if the test plans are inconclusive, BMW calls for replacing both VANOS solenoids and changing the engine oil and filter, followed by a road test.
• Check the oil filter cap: confirm that the insert is present, and replace the cap if it is missing.
• Inspect the camshaft components: BMW notes that, rather than replacing a complete camshaft, only the camshaft bearing ledge and rectangular hook rings should be replaced, and only if they show deep grooves.

BMW’s bulletin calls for replacement of the solenoids rather than cleaning them. Many owners first try clearing the code and changing the oil, but if the code returns, the solenoids or VANOS hardware usually need attention.

Repair Costs

The VANOS solenoids themselves are relatively affordable parts, and on many six-cylinder engines they are accessible at the front of the cylinder head. An oil and filter change is inexpensive. The costs rise sharply when the VANOS gear assemblies themselves must be replaced or when broken bolt pieces have to be retrieved, which BMW says may require removing the oil pan. For cars covered by an open recall, the bolt repair is free at a BMW dealer.

Is It Safe to Drive With a BMW 2A82 Code?

Short trips to a repair shop are usually possible, but continued driving is not recommended. If the cause is a solenoid or oil supply issue, the car will often stay in reduced power mode and run poorly. If the cause is loose or broken VANOS bolts, Motor Authority reports that continued driving could lead to stalling, a no-start condition and engine damage. Broken bolt pieces inside the engine can cause serious harm, so a rattling engine with these codes should be inspected immediately.

BMW 2A82 Code Versus Generic OBD-II Codes

The BMW 2A82 code is a manufacturer-specific code, which means many basic OBD-II readers will not display it. Generic scanners show only standardized P-codes. The generic codes for camshaft timing include P0011, which means intake camshaft timing over-advanced or system performance on Bank 1, and P0014, the equivalent for the exhaust camshaft on Bank 1.

Because a generic code gives far less detail than BMW’s own fault memory, owners who suspect a VANOS problem should use a BMW-capable diagnostic tool or visit a shop with dealer-level software. Reading the exact BMW code, such as 2A82 or 2A87, together with its freeze-frame data makes it much easier to follow BMW’s test plans.

F-Series Equivalent Codes

On later F-series BMWs, the DME uses six-digit fault codes. BMW’s bulletins list 130108 for the intake VANOS and 130308 for the exhaust VANOS as the codes for a camshaft that did not reach its target position. The VANOS bolt bulletin SI B12 14 12 also lists related F-series codes such as 130104 and 130304 among the faults that loose VANOS bolts can trigger.

How to Prevent VANOS Problems on a BMW

Because VANOS depends on clean oil at the right pressure, maintenance has a direct effect on how often a BMW 2A82 code appears. These habits help keep the system healthy:

• Use BMW-approved oil: choose an oil that meets the BMW Longlife specification listed for the engine, and keep the level correct.
• Consider shorter oil change intervals: many BMW specialists recommend changing oil more often than the long factory interval, especially for cars driven hard or in heavy traffic.
• Use quality oil filters and caps: BMW’s own bulletin shows that a missing oil filter cap insert can contribute to VANOS faults.
• Fix oil leaks and warnings early: low oil level reduces the pressure available to the VANOS units.
• Complete recalls: make sure any VANOS bolt recall has been performed by a BMW dealer.

What to Tell Your Mechanic

Share the exact BMW fault codes, when the power loss happens, whether the engine rattles, the date of the last oil change and whether the VANOS bolt recall has been completed. With that information, a technician can follow BMW’s diagnostic order instead of replacing parts by guesswork.

Buyer’s Advice: Checking a Used BMW for VANOS Problems

Many E90 3 Series, E60 5 Series, X3, X5 and Z4 models with these engines are now affordable used cars. Before buying one, follow these steps:

• Run the VIN on the NHTSA recalls website and confirm the VANOS bolt recalls are completed.
• Scan for stored BMW-specific codes with a BMW-capable tool, not only a basic OBD-II reader.
• Ask for service records showing regular oil changes with BMW-approved oil.
• Listen for rattling at idle and test for smooth power delivery when fully warm.
• Have the car inspected by an independent BMW specialist.

For more on BMW engine reliability, see our guides to BMW B48 engine problems and BMW N63 engine problems. Owners considering a diesel should read our BMW 535d reliability report.

FAQ

What does code 2A82 mean on a BMW?

According to BMW, 2A82 means “VANOS intake – stiff; jammed mechanically.” The intake camshaft did not reach the position the engine computer requested, usually because of oil supply problems, a faulty VANOS solenoid or loose VANOS hardware.

What is the difference between BMW 2A82 and 2A87?

Code 2A82 refers to the intake VANOS system, while 2A87 refers to the exhaust VANOS system. They often appear together because both depend on the same oil supply.

Can a bad VANOS solenoid cause a 2A82 code?

Yes. BMW’s bulletin states that restricted or failed VANOS solenoids can starve the VANOS units of oil, and its repair instructions call for replacing both solenoids when the test plans are inconclusive.

Is my BMW covered by the VANOS recall?

Many 2010 to 2012 six-cylinder models were included in the VANOS bolt recalls. The only reliable way to know is to enter the VIN on the NHTSA recalls website or ask a BMW dealer.

Will an oil change fix a BMW 2A82 code?

Sometimes, if the cause is old or low oil. However, BMW’s bulletin pairs the oil change with VANOS solenoid replacement, so if the code returns after an oil change, further diagnosis is needed.

Can I clear a BMW 2A82 code myself?

Yes, a BMW-capable scan tool can clear the code, and the car may return to full power until the fault is detected again. However, clearing the code does not fix the cause. If the 2A82 code returns, the VANOS solenoids, oil supply or VANOS hardware need to be checked using BMW’s diagnostic order.

Will a BMW 2A82 code fail an emissions inspection?

In US states that use OBD-II based emissions or safety inspections, an illuminated check engine light or stored emissions-related faults usually cause the vehicle to fail. VANOS faults affect camshaft timing and engine operation, so the problem should be repaired before an inspection. After a repair, the readiness monitors also need time to complete.

Which BMW engines get the 2A82 code most often?

BMW’s bulletins focus on six-cylinder engines from the E-series and early F-series era, including the N51, N52, N52K, N52T, N54 and N55. These engines power many popular used models, such as the E90 3 Series, E60 5 Series, E70 X5, X3 and Z4, which is why the BMW 2A82 code is so widely searched.

Conclusion

A BMW 2A82 code, often paired with 2A87, tells you that the VANOS system could not move a camshaft as commanded. BMW’s own bulletins point to three main causes: insufficient oil supply, faulty VANOS solenoids and, on many 2010 to 2012 models, loose or broken VANOS bolts covered by recalls. Checking for open recalls, using the right oil and following BMW’s diagnostic order are the best ways to fix the problem without unnecessary expense.
